PRODUCT FEATURES
- The enclosure protection level reaches IP65, and the waterproof performance is good, and it can resist the impact of torrential rain.
- Integral structure design, light weight, good impact resistance, reliable and stable work under vibration environment.
- Accurate light distribution design, combined with mirror high-purity aluminum reflectors, to achieve a wide range of flood lighting, the efficiency of lamps is as high as 77%, which is more than 30% higher than the industry level.
- Integral structure, can adjust the lighting angle in a wide range, with a special bulb maintenance cover, easy installation and maintenance. Advanced shell anti-corrosion coating, anti-corrosion grade reaches WF2, to ensure that the lamps will not corrode in harsh environments such as salt spray.
- According to the national quality control system, after strict reliability and aging tests, the failure rate of lamps is lower.
- Optimized electrical supporting system design makes the electrical efficiency of the lamp up to 90% and the power factor to 0.9.
PRODUCT PARAMETERS
| Item | Symbol | Description | Unit |
| Picture |  |
||
| Rated Voltage | VOLT | 220 | V |
| Power | P | 35/70/100/150 | W |
| Lighting Source | / | MH/HPS | |
| Protection Level | IP | IP65 | IP |
| Lighting Angle | θ | 90/120 | ° |
| Anti-corrosion Grade | / | WF2 | |
| Explosion Proof Grade | / | Ex d IIB T3/T4 | |
| Light Efficiency | η | 90 | Lm/W |
| Frequency | f | 50/60 | Hz |
| Power Factor | PF | ＞0.95 | PF |
| Operating Temperature | TOPR | -30~50 | ℃ |
| Storage Temperature | TOPR | -30~50 | ℃ |
| Color Rendering Index | CRI | ≥65 | RA |
| LED’S Operating Life | LIFE | 50000 | Hours |
| Start-up Time | T | ≤20 | S |
| Executive Standard | / | GB3836.1、GB3836.2 | |
| Weight | / | 15.5 | KG |
| Size | / | Φ627X438X168 | MM |
